Product Details
Place of Origin: china
Brand Name: Tiejun Turnstile
Certification: ISO9001
Model Number: TDH-P503DB
Payment & Shipping Terms
Minimum Order Quantity: 1pc
Price: Negotiation
Packaging Details: carton packing
Delivery Time: 8-15 work days
Payment Terms: L/C, T/T
Supply Ability: 2000 pc per/month
Name: |
Access Control With Alcohol Testing |
Sensor: |
Fuel Cell |
Size: |
1400*335*980mm |
Weight: |
2.8kg |
Camera: |
Wide Angle HD Camera, 1 Mega Pixel With Visible Light And Infrared |
Response Time: |
5 Seconds |
Connection Port: |
USB 2.0, Support USB Interface Expansion |
Name: |
Access Control With Alcohol Testing |
Sensor: |
Fuel Cell |
Size: |
1400*335*980mm |
Weight: |
2.8kg |
Camera: |
Wide Angle HD Camera, 1 Mega Pixel With Visible Light And Infrared |
Response Time: |
5 Seconds |
Connection Port: |
USB 2.0, Support USB Interface Expansion |
cloud server
unlimited device registration
user management
real time monitering
simple data management
| Sensor | Fuel Cell |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -20°C to 50°C |
| Humidity | 20% to 95% |
| Size | 140 x 195 x 400mm |
| Weight | 2.8kg |
| Power | Input: AC 100-240V 50-60Hz 0.8A Output: DC12V 3A |
| Camera | Wide Angle HD Camera, 1 Mega Pixel with visible light and infrared |
| Facial Recognition | Recognition Rate: 99.9% |
| Identification Speed: 300ms (For local database: 10,000 faces) | |
| Memory (in device) | 20,000 test records |
| 20,000 registered faces | |
| Response Time | 5 seconds |
| Sampling System | Automatically takes a deep lung sample |
| Units of Measure | BrAC: mg/L, or other units |
| BAC: grm%, mg/mL, mg/100ml, or other units | |
| Detection Range | 0.00% BAC to 0.40% BAC |
| Accuracy | 0 - 0.10% BrAC ±5% |
| 0.10 - 0.15% BrAC ±8% | |
| >0.15%: ±10% | |
| Calibration | Replaceable alcohol testing module, no need for on-site calibration |
| Sample Time | 4 seconds of continuous blow |
| Recovery Time | 30 seconds after a positive test |
| Connection Port | USB 2.0, support USB interface expansion |
| Extension Port | 1 digital signal, can connect with electric lock and access gate, can choose wiegand output, RS232 or RS485 (either one) |
| Network | WIFI, 4G (optional), Ethernet |
| Body Temp. Measurement | IR Temperature Sensor (optional) |
