Product Details
Place of Origin: china
Brand Name: Tiejun Turnstile
Certification: ISO9001
Model Number: TDH-B809
Payment & Shipping Terms
Minimum Order Quantity: 1pc
Price: Negotiation
Packaging Details: carton packing
Delivery Time: 8-15 work days
Payment Terms: L/C, T/T
Supply Ability: 2000 pc per/month
Name: |
Full Height Sliding Turnstile |
Material: |
304 Stainless Steel,SUS304 Or Carbon Steel Powder Coating |
Power Supply: |
AC220V/110V |
Net Weight: |
200kgs |
Warranty: |
1 Year |
Passing Speed: |
30-40 Persons/min |
Passage Width: |
<=600mm |
Power Consumption: |
40W |
Color: |
Optional,Silver,SSB(US32D)- Stainless Steel Brushed / Powder Coating,Silver White Or Customize |
Type: |
Single Core & Double Core,automatic Tripod Turnstile,Full Height Turnstile |
Housing Material: |
304 Stainless Steel |
Communication Interface: |
RS485(Distance |
Gross Weight: |
215kgs |
Certification: |
ISO,CE,RoHS |
Name: |
Full Height Sliding Turnstile |
Material: |
304 Stainless Steel,SUS304 Or Carbon Steel Powder Coating |
Power Supply: |
AC220V/110V |
Net Weight: |
200kgs |
Warranty: |
1 Year |
Passing Speed: |
30-40 Persons/min |
Passage Width: |
<=600mm |
Power Consumption: |
40W |
Color: |
Optional,Silver,SSB(US32D)- Stainless Steel Brushed / Powder Coating,Silver White Or Customize |
Type: |
Single Core & Double Core,automatic Tripod Turnstile,Full Height Turnstile |
Housing Material: |
304 Stainless Steel |
Communication Interface: |
RS485(Distance |
Gross Weight: |
215kgs |
Certification: |
ISO,CE,RoHS |
| Square Cross Full height Turnstiles<TDH-Q802>Product Specifications | ||||
| Document Number: | ||||
| Edition: | A/0 | |||
| Revision Time: | ||||
| Revised by: | ||||
| Product Parameters | Dimensions: | Double:1460*1230*2180mmCustomized) |
Box Material: | Box: Stainless steel SUS304 foot 1.2mm Rotary Bar: Stainless steel SUS304 foot 2.0mm |
| Swing Arm Material: | Stainless steel SUS304 | Channel Width: | 675MM(Customized) | |
| Technical Parameters | ◆Chassis Material: Austenitic stainless steel SUS304 ◆Internal Structure: Steel Frame Construction/Standard Stainless Steel Housing; ◆Work Voltage: AC220V±10V ◆Normal Work Life: Continuous opening and closing for more than 5 million times ◆Working Environment Temperature: -35℃～75℃ ◆Relative Humidity: 0～90%(No condensation) ◆Communication Interface: Switching electrical signal, extensible RS232 serial port ◆Working Speed of the Gate: ≤20 persons/min(The memory mode can be turned on) ◆Passing Time: passing time by swiping card: 5S(If no one passes within 10S: the gate will automatically close, and the time can be adjusted according to needs) |
|||
| Function Parameters | Basic Functions | ●Passing Indicator Function: The LED indicator board is installed in the eye-catching part of the housing frame to prompt pedestrains the gate's passing status annd direction. | ||
| ●Anti-trepass function: when the card is invalid, no card is swiped or the passage is forbidden, pushing the bar focibly will be regarded as illegal entry, and the system will alarm and lock the brake rode automatically. (so that it could not be pushed) | ||||
| ●Access Control: The external port can be connected to a variety of biometric identification devices. | ||||
| ●Anti-interference: To prevent the gate abnormal caused by electromagnetic and other external causes. | ||||
| Extensible Functions | ▲Intelligent Linkage Alarm: Can be linked with other alarm monitoring equimpemnet； | |||
| ▲Voice broadcast, expandable voice module, and volume adjustment. | ||||
| ▲Switch on/Switch off Delay: set the delay of switch off after the switch machine receives the switch off signal/set the delay of switch off after the pedestrian passes. The default value is 0 seconds. | ||||
| ▲Fire Linkage △Normally open mode: the gate maintains the open state; △ Normally closed mode: the gate maintains the switch state. |
||||
| ▲Passage Mode △Bidirectional passage, swiping card bi-directionally for people flow. △Bidirectional free passage, no credit card verification is required. △Unidirectional passage, unidirectional (A) swiping card, and the gate opens normally for people flow; reverse directional (B) swiping card is invalid, and the gate closes. △Unidirectional free passage, unidirectional (A) free passage, and reverse directional passing (B) require a swiping card verification. △Passing is prohibited, Bidirectional swiping card is invaild, and the gate enters the locked state. |
||||
Application
Suitable for indoor / outdoor pedestrian passages; such as: scenic spots, parks, playgrounds / primary and secondary schools / colleges / office buildings / hotels / residential quarters / factory parks / hospitals / enterprises and institutions / government halls / sports venues, etc.;
